中频感应电炉专用软管 还原电炉绝缘软管 JY10
Applications:
it is suitable for conveying purified water through cable in induction electric furnace water cooling system with voltage of 10KV. Pure carbon - free, high insulation, wear - resistant, anti - aging.
Construction:
Tube: white, smooth, pure, carbon-free, high-insulated EPDM synthetic rubber.
Reinforcement: high strength polyester fiber.
Cover: white or green, pure carbon - free, high - insulation EPDM synthetic rubber. Smooth for ID≤1", fabric impression for ID＞1”.
Electrical resistance: high insulation, excellent low leakage current. At 10KV DC/AC voltage, the leakage current is less than 20 Micro Amp.
Temperature range: -40 °C +120 °C
Environmental standards: EU pahs-2, REACH, ROHS directive.
Technical standard: HG/T2184, CJAN
应用范围：
适用于电压10KV内感应电炉水冷系统穿电缆输送纯净水。纯净无碳，高绝缘，耐磨、抗老
化。
软管结构：
内管：白色，光滑、纯净、无碳、高绝缘的EPDM合成橡胶。
增强层: 高强度聚酯纤维线。
外管：白色，光面（1"以上为布面）纯净无碳、高绝缘EPDM合成橡胶；其他绿色/红色/蓝色可根据客户要求定制。
耐电压：
高绝缘，优秀的低泄露电流。在10KV DC/AC电压下，泄露电流小于20 Micro Amp。
适用温度：-40 to 120 ℃。
环保标准：符合欧盟PAHS-2、REACH、ROHS指令。
技术标准：HG/T2184, CJAN
编码
|
内径
|
外径
|
弯曲半径
|
工作压力
|
爆破压力
|
重量
|
每卷长度
|
inch
|
mm
|
mm
|
mm
|
PSI
|
PSI
|
kg/m
|
m
|
JY10013
|
1/2"
|
12.7
|
22.0
|
100
|
300
|
1200
|
0.31
|
100
|
JY10016
|
5/8"
|
15.9
|
25.0
|
120
|
300
|
1200
|
0.35
|
60
|
JY10019
|
3/4"
|
19.0
|
29.0
|
150
|
300
|
1200
|
0.46
|
60
|
JY10022
|
7/8"
|
22.2
|
33.0
|
170
|
300
|
1200
|
0.58
|
60
|
JY10025
|
1"
|
25.4
|
38.0
|
200
|
300
|
1200
|
0.76
|
60
|
JY10032
|
1-1/4"
|
31.8
|
50.0
|
250
|
250
|
1000
|
1.1
|
40
|
JY10038
|
1-1/2"
|
38.1
|
56.0
|
300
|
250
|
1000
|
1.38
|
40
|
JY10042
|
42mm
|
42.0
|
60.0
|
336
|
250
|
1000
|
1.46
|
40
|
JY10045
|
45mm
|
44.5
|
62.5
|
360
|
250
|
1000
|
1.6
|
40
|
JY10050
|
2"
|
50.8
|
68.8
|
400
|
250
|
1000
|
1.9
|
40
|
JY10063
|
2-1/2"
|
63.5
|
81.5
|
500
|
200
|
800
|
2.5
|
40
|
JY10076
|
3"
|
76.2
|
94.2
|
600
|
150
|
600
|
3.2
|
40
|
