| 性能规范Technical Data |
公称压力
Nominal Pressure(MPa) |
公称通径
Nominal Diameter(mm) |
适用介质
Applicable Medium |
| 0.6 |
50 - 150 |
|
0.4
|
175 - 300
|
海水、淡水、滑油
Sea water. Fresh water, Lu bricanting oil |
| 0.25 |
350 - 500 |
|
|
|
| 主要零部件材质Materials of Main Parts |
| 零件名称 |
材料Material |
Parts Name
|
名称Name |
牌号Marks |
阀体、阀盖、阀芯
Body/Cover/Disc |
灰铸铁、铸钢、铸锡青铜
Gray Cast lron/Cast Steel/Cast Tin Bronze |
HT200. ZG230-450. ZCuSn102n2 |
阀杆、螺母
Stem／Nut |
佃日“ 不锈钢
Aluminum Bronze/Stainless Steel |
CuA19Mn2. 2Cr13
|
密封圈
Seal Ring |
t口月’不锈钢
Aluminum Bronze/Stainless Steel |
CuA19Mn2. 1Cr18Ni9Ti. 2Cr13 |
|
| A型的基本尺寸Dimensions |
公称
压力
DN |
公称
通径
DN |
结构尺寸
Structure Dimension
|
法兰Flange
|
螺栓Bont
|
壁厚
Thickness |
阀杆Stem
|
手轮
Hand
wheel |
升程
Lift
Range |
参考
重量
Weight |
| (MPa) |
(mm) |
L≈ |
H≈ |
D |
Di |
D2 |
do |
b |
n个 |
Th |
6 |
d |
口 |
Do |
m |
(kg) |
| |
40 |
170 |
330 |
125 |
93 |
74 |
15 |
13 |
6 |
M14 |
6 |
Tr20 x 8(P4)LH |
14 |
160 |
48 |
15 |
| |
50 |
190 |
340 |
135 |
103 |
84 |
15 |
16 |
6 |
M14 |
8 |
Tr20 x 8(P4)LH |
14 |
180 |
60 |
20 |
| |
65 |
200 |
372 |
155 |
123 |
104 |
15 |
15 |
6 |
M14 |
9 |
Tr20 x 8(P4)LH |
14 |
180 |
75 |
24 |
| 0.6 |
80 |
220 |
430 |
170 |
138 |
1 18 |
15 |
15 |
8 |
M14 |
9 |
Tr24 x 10(P5)LH |
17 |
200 |
92 |
33 |
| |
100 |
220 |
460 |
190 |
158 |
138 |
15 |
15 |
8 |
M14 |
10 |
Tr24 x 10(P5)LH |
17 |
200 |
112 |
40 |
| |
125 |
242 |
528 |
215 |
183 |
164 |
15 |
15 |
10 |
M14 |
10 |
Tr26 x 10(P5)LH |
19 |
225 |
138 |
61 |
| |
150 |
248 |
566 |
240 |
208 |
190 |
15 |
16 |
12 |
M14 |
11 |
Tr26 x 10(P5)LH |
19 |
225 |
165 |
70 |
| |
175 |
268 |
630 |
270 |
238 |
221 |
15 |
16 |
12 |
M14 |
11 |
Tr28 x 10(P5)LH |
22 |
250 |
190 |
85 |
0.4 |
200
|
278
|
685
|
295
|
264
|
247
|
15
|
16
|
12
|
M14
|
11
|
Tr28 x 10(P5)LH
|
22
|
250
|
215
|
100
|
| |
250 |
310 |
755 |
365 |
327 |
306 |
17 |
18 |
14 |
M16 |
13 |
Tr30 x 10(P5)LH |
24 |
280 |
265 |
153 |
| |
300 |
345 |
835 |
430 |
386 |
360 |
21 |
19 |
14 |
M20 |
13 |
Tr30 x 10(P5)LH |
24 |
280 |
315 |
199 |
|
|
| AS鹫的基本尺寸Dimensions |
公称
压力
DN |
公称
通径
DN |
结构尺寸
Structure Dimension
|
法兰Flange
|
螺栓Bont
|
壁厚
Thickness |
阀杆Stem
|
手轮
Hand
wheel |
升程
Lift
Range |
参考
重量
Weight |
| (MPa) |
(mm) |
L≈ |
H≈ |
D |
Di |
D2 |
do |
b |
n个 |
Th |
6 |
d |
口 |
Do |
m |
(kg) |
| |
40 |
165 |
330 |
130 |
100 |
80 |
14 |
16 |
4 |
M12 |
6 |
Tr20 x 8(P4)LH |
14 |
160 |
48 |
17 |
| |
50 |
178 |
340 |
140 |
110 |
90 |
14 |
16 |
4 |
M12 |
8 |
Tr20 x 8(P4)LH |
4 |
180 |
60 |
20.3 |
| |
65 |
190 |
372 |
160 |
130 |
1 10 |
14 |
16 |
4 |
M12 |
9 |
Tr20 x 8(P4)LH |
14 |
180 |
75 |
24.5 |
| 0.6 |
80 |
203 |
430 |
190 |
150 |
128 |
18 |
18 |
4 |
M16 |
9 |
Tr24 x 10(P5)LH |
17 |
200 |
92 |
33.8 |
| |
100 |
229 |
460 |
210 |
170 |
148 |
18 |
18 |
4 |
M16 |
10 |
Tr24 x 10(P5)LH |
17 |
200 |
112 |
41.2 |
| |
125 |
254 |
528 |
240 |
200 |
178 |
18 |
20 |
8 |
M16 |
10 |
Tr26 x 10(P5)LH |
19 |
225 |
138 |
62.1 |
| |
150 |
267 |
566 |
265 |
225 |
202 |
18 |
20 |
8 |
M16 |
11 |
Tr26 x 10(P5)LH |
19 |
225 |
165 |
71.6 |
| |
175 |
292 |
630 |
295 |
255 |
232 |
18 |
22 |
8 |
M16 |
11 |
Tr28 x 10(P5)LH |
22 |
250 |
190 |
86.4 |
0.4 |
200
|
292
|
685
|
320
|
280
|
258
|
18
|
22
|
8
|
M16
|
11
|
Tr28 x 10(P5)LH
|
22
|
250
|
215
|
101.8
|
| |
250 |
330 |
755 |
375 |
335 |
312 |
18 |
24 |
12 |
M16 |
13 |
Tr30 x 12(P6)LH |
24 |
280 |
265 |
155.1 |
| |
300 |
356 |
835 |
440 |
395 |
365 |
22 |
24 |
12 |
M20 |
13 |
Tr30 x 12(P6)LH |
24 |
280 |
315 |
201.2 |
| |
350 |
381 |
1050 |
490 |
445 |
415 |
22 |
26 |
12 |
M20 |
14 |
Tr36 x 12(P6)LH |
27 |
320 |
365 |
298.3 |
0.25 |
400
|
406
|
1145
|
540
|
495
|
465
|
22
|
28
|
16
|
M20
|
15
|
Tr36 x 12(P6)LH
|
27
|
360
|
418
|
372.1
|
| |
450 |
432 |
1330 |
595 |
550 |
520 |
22 |
28 |
16 |
M20 |
16 |
Tr40 x 12(P6)LH |
32 |
400 |
468 |
560.0 |
| |
500 |
457 |
1420 |
645 |
600 |
570 |
22 |
30 |
20 |
M20 |
16 |
Tr40 x 12(P6)LH |
32 |
450 |
518 |
627.4
|
|
