螺纹连接的外形及连接尺寸(图一)
|
|
|
Model
型号
|
DN
|
G
|
H
|
E
|
L
|
GUD-10(G)
|
10
|
1/4"
|
153
|
157
|
68
|
GUD-16(G)
|
16
|
1/2"
|
172
|
157
|
72
|
GUD-20(G)
|
20
|
3/4"
|
178
|
157
|
82
|
GUD-25(G)
|
25
|
1"
|
187
|
157
|
90
|
GUD-32(G)
|
32
|
1-1/4"
|
206
|
157
|
112
|
GUD-40(G)
|
40
|
1-1/2"
|
212
|
157
|
120
|
GUD-50(G)
|
50
|
2"
|
265
|
157
|
145
|
GUD-63(G)
|
63
|
2-1/2"
|
305
|
207
|
185
|
GUD-80(G)
|
80
|
3"
|
330
|
207
|
210
|
GUD-100(G)
|
100
|
4"
|
350
|
207
|
268
|
|
|
■
|
活套法兰连接(GB6070)(图二)
|
|
|
Model
型号
|
DN
|
D
|
Do
|
H
|
E
|
L
|
n-φc
|
GUD-10(F)
|
10
|
55
|
40
|
153
|
157
|
84
|
4-φ6.6
|
GUD-16(F)
|
16
|
60
|
45
|
172
|
157
|
84
|
4-φ6.6
|
GUD-25(F)
|
25
|
70
|
55
|
187
|
157
|
114
|
4-φ6.6
|
GUD-32(F)
|
32
|
90
|
70
|
206
|
157
|
140
|
4-φ9
|
GUD-40(F)
|
40
|
100
|
80
|
212
|
157
|
160
|
4-φ9
|
GUD-50(F)
|
50
|
110
|
90
|
265
|
157
|
170
|
4-φ9
|
GUD-63(F)
|
63
|
130
|
110
|
305
|
207
|
195
|
4-φ9
|
GUD-80(F)
|
80
|
145
|
125
|
330
|
207
|
203
|
8-φ9
|
GUD-100(F)
|
100
|
165
|
145
|
350
|
207
|
280
|
8-φ9
|
|
|
■
|
快卸法兰连接(GB4982)(图三)
|
|
|
Model
型号
|
DN
|
D1
|
D
|
H
|
E
|
L
|
GUD-10(KF)
|
10
|
12.2
|
30
|
153
|
157
|
84
|
GUD-16(KF)
|
16
|
17.2
|
30
|
172
|
157
|
84
|
GUD-25(KF)
|
25
|
26.2
|
40
|
187
|
157
|
114
|
GUD-32(KF)
|
32
|
34.2
|
55
|
206
|
157
|
140
|
GUD-40(KF)
|
40
|
41.2
|
55
|
212
|
157
|
160
|
GUD-50(KF)
|
50
|
52.2
|
75
|
265
|
157
|
170
|
|
|
